MEAN WELL NTS-250P / NTS-400P Series 250W-400W Built-in Type True Sine Wave DC-AC Inverters with Fanless Design

模型：

MEAN WELL NTS-400P-112 400W DC-AC true sine wave inverter

SKU：

776851212154-MEAN WELL NTS-250P / NTS-400P Series

產品類型：

直流/交流

MOQ：

1 件

MEAN WELL NTS-250P-124 and NTS-400P-124 in stock. 250W/400W high-reliable built-in type true sine wave DC-AC power inverters with 24V DC input (20-33V range) . Features true sine wave output with <3% THD . NTS-250P offers 500W peak power (fanless, convection cooled) while NTS-400P offers 800W surge power (250W convection, 400W forced air) .

價格範圍：$103.00 到 $111.00

選項

輸出電壓*

100/110/115/120V
200/220/230/240V

Input Voltage

清除

計算運費

請在以下欄位填寫運送目的地的詳細資料，以便計算運費。.

計算

加入購物清單

快速出貨

運費和交貨日期待議。立即與我們聯絡，瞭解更多詳情。.

安全付款

您在 c2psu.com 上的每筆付款都經過嚴格的 SSL 加密和 PCI DSS 資料保護協定保護。

輕鬆返回

對符合條件的購物進行免費本地瑕疵退貨

退款保障

如果您的訂單未寄送、遺失或到貨時出現產品問題，請申請退款

MEAN WELL NTS-250P-124 and NTS-400P-124 in stock. 250W/400W high-reliable built-in type true sine wave DC-AC power inverters with 24V DC input (20-33V range) . Features true sine wave output with <3% THD . NTS-250P offers 500W peak power (fanless, convection cooled) while NTS-400P offers 800W surge power (250W convection, 400W forced air) .
AC output voltage selectable via DIP switch: 100/110/115/120V or 200/220/230/240V with 50/60Hz selection . Includes remote ON/OFF control, Tx/Rx computer communication interface for status monitoring, and energy-saving mode with <1.5W no-load consumption .
Comprehensive protections: input reverse polarity, DC low voltage alarm/shutdown, over voltage, output short circuit, overload, over temperature . Suitable for lead-acid and lithium batteries with conformal coated PCB.
Operating temperature -20°C to +70°C.
Compact dimensions 186 x 100.5 x 32mm. 3-year warranty .
Safety approvals: CB, E13, EAC, RCM, CE, FCC .

Key NTS-250P/400P Series Features Summary:

Feature	NTS-250P	NTS-400P
Rated Power	250W	400W
Peak/Surge Power	500W (peak)	800W (surge, 30 cycles)
Cooling Method	Fanless, convection cooled	250W convection / 400W forced air
Waveform	True sine wave, THD <3%	True sine wave, THD <3%
AC Output Adjustment	DIP switch selectable (100-120V or 200-240V)	DIP switch selectable (100-120V or 200-240V)
Frequency	50/60Hz selectable by DIP switch	50/60Hz selectable by DIP switch
Efficiency	Up to 92%	Up to 93%
No-Load Consumption	<1.5W in energy-saving mode	<1.5W in energy-saving mode
Remote Control	Built-in remote ON/OFF	Built-in remote ON/OFF
Communication	Tx/Rx for monitoring	Tx/Rx for monitoring
Battery Compatibility	Lead-acid or lithium batteries	Lead-acid or lithium batteries
Protections	Reverse polarity, low voltage alarm/shutdown, over voltage, short circuit, overload, over temp	Reverse polarity, low voltage alarm/shutdown, over voltage, short circuit, overload, over temp
Operating Temperature	-20°C to +70°C (derating above +40°C)	-20°C to +70°C (derating above +40°C)
Dimensions (L×W×H)	186 × 100.5 × 32 mm	186 × 100.5 × 32 mm
Safety Approvals	CB, E13, EAC, RCM, CE, FCC	CB, E13, EAC, RCM, CE, FCC
保固	3 years	3 years
