MEAN WELL NTS-250P / NTS-400P Series 250W-400W Built-in Type True Sine Wave DC-AC Inverters with Fanless Design
model:
MEAN WELL NTS-400P-112 400W DC-AC true sine wave inverter
SKU:
776851212154-MEAN WELL NTS-250P / NTS-400P Series
Product Type :
DC/AC
MOQ:
1 Piece
ไปทๆ ผ่ๅด๏ผ$103.00 ่ณ $111.00
Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.
After Sales Assurance
Refund for No Delivery
Secure Payment
Logistics Support
Free Shippingย
X Days Delivery
On Time Guaranteeย
Free Return
Fast shipping
Shipping fee and delivery date to be negotiated. Chat with US now for more details.
Secure payments
Every payment you make on c2psu.com is secured with strict SSL encryption and PCI DSS data protection protocols
Easy Return
Make free local returns for defects on qualifying purchases
Money-back protection
Claim a refund if your order doesn’t ship, is missing, or arrives with product issues
-
MEAN WELL NTS-250P-124 and NTS-400P-124 in stock. 250W/400W high-reliable built-in type true sine wave DC-AC power inverters withย 24V DC inputย (20-33V range)ย . Featuresย true sine wave output with <3% THDย . NTS-250P offers 500W peak power (fanless, convection cooled) while NTS-400P offers 800W surge power (250W convection, 400W forced air)ย .
-
AC output voltage selectable via DIP switch: 100/110/115/120V or 200/220/230/240V with 50/60Hz selectionย . Includes remote ON/OFF control, Tx/Rx computer communication interface for status monitoring, and energy-saving mode with <1.5W no-load consumptionย .
-
Comprehensive protections: input reverse polarity, DC low voltage alarm/shutdown, over voltage, output short circuit, overload, over temperatureย . Suitable for lead-acid and lithium batteries with conformal coated PCB.
-
Operating temperature -20ยฐC to +70ยฐC.
-
Compact dimensions 186 x 100.5 x 32mm. 3-year warrantyย .
-
Safety approvals: CB, E13, EAC, RCM, CE, FCCย .
Key NTS-250P/400P Series Features Summary:
| Feature | NTS-250P | NTS-400P |
|---|---|---|
| Rated Power | 250W | 400W |
| Peak/Surge Power | 500W (peak) | 800W (surge, 30 cycles) |
| Cooling Method | Fanless, convection cooled | 250W convection / 400W forced air |
| Waveform | True sine wave, THD <3% | True sine wave, THD <3% |
| AC Output Adjustment | DIP switch selectable (100-120V or 200-240V) | DIP switch selectable (100-120V or 200-240V) |
| Frequency | 50/60Hz selectable by DIP switch | 50/60Hz selectable by DIP switch |
| Efficiency | Up to 92% | Up to 93% |
| No-Load Consumption | <1.5W in energy-saving mode | <1.5W in energy-saving mode |
| Remote Control | Built-in remote ON/OFF | Built-in remote ON/OFF |
| Communication | Tx/Rx for monitoring | Tx/Rx for monitoring |
| Battery Compatibility | Lead-acid or lithium batteries | Lead-acid or lithium batteries |
| Protections | Reverse polarity, low voltage alarm/shutdown, over voltage, short circuit, overload, over temp | Reverse polarity, low voltage alarm/shutdown, over voltage, short circuit, overload, over temp |
| Operating Temperature | -20ยฐC to +70ยฐC (derating above +40ยฐC) | -20ยฐC to +70ยฐC (derating above +40ยฐC) |
| Dimensions (LรWรH) | 186 ร 100.5 ร 32 mm | 186 ร 100.5 ร 32 mm |
| Safety Approvals | CB, E13, EAC, RCM, CE, FCC | CB, E13, EAC, RCM, CE, FCC |
| Warranty | 3 years | 3 years |
