Alimentatori CA/CC, Adattatore c.a. c.c.

Marchio:

Certificato

MEAN WELL GSM40B / GSM60B / GSM90B / GSM120B / GSM160B / GSM220B Series 12V 24V 40W-220W Medical Desktop Power Supplies, Class II, Level VI

modello:

MEAN WELL GSM Series 40W-220W 12V 24V Medical Desktop Power Supplies, Class I

SKU:

776851212158-MEAN WELL GSM Series Medical Power Supplies Class II

Tipo di prodotto :

AC/DC

MOQ:

1 pezzo

Discover the MEAN WELL GSM “B” series—40W to 220W high-reliability medical-grade desktop power adapters featuring Class II construction with 2-pole IEC320-C8 AC inlet (no ground pin required) . Certified to ANSI/AAMI ES60601-1 and IEC60601-1 (2xMOPP) with ultra-low leakage current <50µA (40W-60W) to <100µA (90W-220W), suitable for BF patient contact medical devices with appropriate system consideration . Energy efficiency Level VI with no-load power consumption <0.1W (40W-60W) to <0.15W (90W-220W), complying with EISA 2007/DoE, NRCan, and EU ErP . Available in popular output voltages including 12V and 24V models with output current up to 15A (12V) and 9.2A (24V) on 220W models . Fanless design with wide operating temperature -30°C to +70°C (60W-220W) . Fully enclosed UL94V-0 flame retardant plastic case with protections: short circuit, overload, over voltage, over temperature . 3-year warranty. Ideal for mobile clinical workstations, patient monitoring systems, portable hemodialysis machines, and home healthcare equipment .

Fascia di prezzo: da $14.50 a $58.50

Opzione

Svuota

Calculate shipping price

Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.

Calculate

Aggiungi alla lista dei desideri

Spedizione veloce

Spese di spedizione e data di consegna da negoziare. Chatta con noi ora per maggiori dettagli.

Pagamenti sicuri

Ogni pagamento effettuato su c2psu.com è protetto da una rigorosa crittografia SSL e da protocolli di protezione dei dati PCI DSS.

Ritorno facile

Effettuate resi locali gratuiti per difetti su acquisti qualificati

Protezione soddisfatti o rimborsati

Chiedete un rimborso se il vostro ordine non viene spedito, è mancante o arriva con problemi di prodotto.

Key GSM “B” Series (Class II) Features Summary (40W-220W):

Feature	GSM40B	GSM60B	GSM90B	GSM120B	GSM160B	GSM220B
Power Rating	40W	60W	90W	120W	160W	220W
Input	80-264VAC, 47-63Hz with PFC	80-264VAC with PFC	80-264VAC with PFC	80-264VAC with PFC	80-264VAC with PFC	80-264VAC with PFC
AC Inlet Type	IEC320-C8 (2-pole, Class II, no ground)	IEC320-C8	IEC320-C8	IEC320-C8	IEC320-C8	IEC320-C8
12V Models	3.34A	5A	7.5A	8.5A	11.5A	15A
24V Models	1.67A	2.5A	3.75A	5A	6.67A	9.2A
Medical Safety	2×MOPP, ANSI/AAMI ES60601-1	2×MOPP	2×MOPP	2×MOPP	2×MOPP	2×MOPP
Leakage Current	<50μA	<50μA	<100μA	<100μA	<100μA	<100μA
Efficiency Level	Level VI	Level VI (88-91.5%)	Level VI (up to 91%)	Level VI (up to 91.5%)	Level VI (up to 92%)	Level VI (up to 94.5%)
No-Load Consumption	<0.1W	<0.1W	<0.15W	<0.15W	<0.15W	<0.15W
Operating Temperature	-30°C to +60°C	-30°C to +70°C	-30°C to +60°C	-30°C to +70°C	-30°C to +70°C	-30°C to +70°C
Standard DC Connector	P1J (2.1×5.5mm)	P1J (2.1×5.5mm)	P1J	R7B (4-pin DIN lock)	R7B (4-pin DIN lock)	R7B (4-pin DIN lock)
Dimensions (L×W×H)	125×50×31.5mm	125×50×31.5mm	154.5×66×33mm	167×67×35mm	175×72×35mm	210×85×46mm
Garanzia	3 years	3 years	3 years	3 years	3 years	3 years

Model Number Breakdown:

GSM40B = 40W desktop series, Class II (IEC320-C8 inlet) GSM60B = 60W desktop series, Class II GSM90B = 90W desktop series, Class II GSM120B = 120W desktop series, Class II GSM160B = 160W desktop series, Class II GSM220B = 220W desktop series, Class II

Example: GSM160B24-R7B
