Discover the MEAN WELL AD, ADD, and ADS series—specialized AC/DC power supplies with dual and triple outputs designed specifically for security, access control, and CCTV applications . These compact enclosed power supplies provide 2 or 3 independent output channels from a single unit, simplifying installation and reducing costs for multi-voltage security systems . Universal AC input 85-264VAC with high efficiency up to 88% and no-load power consumption <0.75W .
Available models include:
-
AD series: 35W-155W, dual outputs (12V/24V combinations) with battery charging function
-
ADD series: 35W-75W, dual outputs for door access control systems
-
ADS series: 40W-60W, triple outputs for security systems requiring multiple voltages
Key features include battery reverse polarity protection, temperature compensation (via external NTC), and comprehensive protections (short circuit/overload/over voltage) . Operating temperature -20°C to +60°C with free air convection cooling. 3-year warranty. Ideal for access control panels, CCTV cameras, fire alarm systems, and central monitoring stations .
Model Number Breakdown:
AD Series (Dual Output with Battery Charger):
| Model | Output 1 | Output 2 | Total Power |
|---|---|---|---|
| AD-55 | 13.8V / 2.5A (35W) | 27.6V / 0.5A (14W) | 55W |
| AD-155 | 13.8V / 6.5A (90W) | 27.6V / 1.5A (41W) | 155W |
-
Universal AC input 85-264VAC
-
Battery charging function on main output
-
Protections: SCP/OLP/OVP/battery reverse polarity
-
Dimensions: 129×98×38mm (AD-55), 199×110×50mm (AD-155)
ADD Series (Dual Output for Access Control):
| Model | Output 1 | Output 2 | Total Power |
|---|---|---|---|
| ADD-35 | 13.8V / 1.2A (16.6W) | 13.8V / 1.2A (16.6W) | 35W |
| ADD-55 | 13.8V / 2.5A (34.5W) | 13.8V / 1.5A (20.7W) | 55W |
| ADD-75 | 13.8V / 3.6A (49.7W) | 13.8V / 2.1A (29W) | 75W |
-
Universal AC input 85-264VAC
-
Protections: SCP/OLP/OVP
-
Dimensions: 99×97×36mm (ADD-35), 129×98×38mm (ADD-55), 159×97×38mm (ADD-75)
ADS Series (Triple Output):
| Model | Output 1 | Output 2 | Output 3 | Total Power |
|---|---|---|---|---|
| ADS-40 | 13.8V / 1.7A (23.5W) | 5V / 0.5A (2.5W) | 13.8V / 0.5A (6.9W) | 40W |
| ADS-60 | 13.8V / 3.2A (44.2W) | 5V / 0.5A (2.5W) | 13.8V / 0.5A (6.9W) | 60W |
-
Universal AC input 85-264VAC
-
Protections: SCP/OLP/OVP
-
Dimensions: 129×98×38mm (ADS-40), 159×97×38mm (ADS-60)
All series feature operating temperature -20°C to +60°C, efficiency up to 88%, no-load consumption <0.75W, and 3-year warranty . Safety approvals: UL/CUL/CB/CE/EAC .
